Airtac 2KL Solenoid Valve 2KL05010BI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL05010BI Solenoid Valve Technical Details
- Model: 2KL05010BI
- Type: 5/2-way monostable (double solenoid optional)
- Port size: G1/8 (ISO228 standard)
- Thread type: BSPP (parallel threads with O-ring seal)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max flow rate: 850 NL/min (ANR, at 0.5 MPa)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W max | AC: 4.5VA max
- Response time: ≤15ms (exhaust to full flow)
- Weight: 220g ±5% (without connector)
- Dimensions: 53mm(L) × 38mm(W) × 72mm(H)
- Core material: Nickel-plated brass body
- Seal material: Heat-resistant HNBR (-20℃ to 120℃)
- Ambient temp range: -5℃ to 60℃ (non-freezing)
- Protection rating: IP67 (dustproof & temporary immersion)
- Porting pattern: ISO 5599-1 compliant (modular design)
High-flow directional control valve with manual override, featuring anti-vibration design for industrial environments. The 2KL series utilizes a moving coil system with surge protection circuitry, achieving 10 million cycles MTBF. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Pneumatic cylinder sequencing in automated assembly lines
- Clamping/unclamping mechanisms in CNC machining centers
- Vacuum cup control systems for material handling robots
- Textile machinery thread tension regulation
- Beverage canning line actuator control
Installation protocol:
Mount with M4 screws (torque ≤0.8N·m). Maintain ≥15mm clearance
below valve for manifold heat dissipation. Use shielded cables
when installed near frequency converters.
Maintenance alert:
Replace internal filters every 5,000 operating hours. Avoid silicone-based
lubricants - use ISO VG32 turbine oil for maintenance.
| Property | Property Value |
|---|---|
| sku | 2KL05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
