Airtac 2KWX Fluid Solenoid Valve 2KWX03008BI
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX Fluid Solenoid Valve 2KWX03008BI Technical Details
- Model: 2KWX03008BI
- Type: 3-position, 5-way direct-acting solenoid valve
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Max flow rate: 1200 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Coil insulation class: Class F (155℃)
- Protection rating: IP67 (dust/water resistant)
- Weight: 320g ±5g (including coil)
- Dimensions: 56mm(W) × 45mm(H) × 103mm(L)
- Port thread depth: 12mm (minimum engagement)
- Mounting orientation: Any (horizontal/vertical)
High-flow proportional control valve with reinforced epoxy coil housing and corrosion-resistant brass body. Features manual override button for system debugging and low-hysteresis spool design for precise flow regulation. Compatible with compressed air, inert gases, and non-lubricated media.
- Automated liquid dispensing systems
- Plastic injection molding machines
- Coolant flow control in CNC equipment
- Beverage production line pneumatic circuits
- Semiconductor manufacturing gas control
Installation protocol:
Install downstream filter regulator (5-40μm). Maintain minimum 30cm distance from high-frequency inverters.
For continuous operation, use surge protection module (optional PZ-01S).
| Property | Property Value |
|---|---|
| sku | 2KWX03008BI |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC24V |
