Airtac 2KWX Fluid Solenoid Valve 2KWX05010AI
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX Fluid Solenoid Valve 2KWX05010AI Technical Details
- Model: 2KWX05010AI
- Type: 5-port, 2-position (5/2-way) direct-acting solenoid valve
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 1,200 L/min (Cv=1.8) at 0.5 MPa
- Response time: ≤30ms (energize), ≤20ms (de-energize)
- Operating temperature: -5℃ to 80℃ (with NBR seals)
- Seal material: Standard NBR, optional FKM/Viton for high temp
- Protection class: IP67 (dust-tight & protected against temporary immersion)
- Weight: 420g ±5% (excluding connectors)
- Dimensions: 62mm(L) × 40mm(W) × 85mm(H) (manual override protrudes 12mm extra)
- Port thread depth: 10mm (minimum engagement required)
High-flow solenoid valve with dual-coil latching design for energy-efficient operation. Features anodized aluminum body with PPS resin coil housing for chemical resistance. Includes manual override and position indicator. Compatible with compressed air (lubricated/non-lubricated) and neutral gases. Requires 5μm filtration for optimal performance.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum pump control systems
- Medical equipment gas flow management
- Food processing machinery (FDA-compliant versions available)
- Semiconductor fab automation
Installation guidelines:
Mount in vibration-free area using M5 mounting screws (included).
Maintain 15mm clearance below valve for electrical connections.
Use 18-24AWG wires with 500mm max lead length.
For horizontal mounting, install exhaust silencers vertically downward.
Do NOT use with oxygen systems or flammable gases.
Cycle rate limited to 5Hz continuous operation.
Apply dielectric grease to electrical contacts in humid environments.
| Property | Property Value |
|---|---|
| sku | 2KWX05010AI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
