Airtac 2KWX Fluid Solenoid Valve 2KWX05010BI
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX05010BI Fluid Solenoid Valve Specifications
- Model: 2KWX05010BI
- Type: 5-port, 2-position (5/2-way) with single solenoid operator
- Port size: G1/8 (ISO228/1 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Maximum flow rate: 750 L/min (Cv=1.3 at 0.5 MPa)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -10℃ to 80℃ (with intermittent operation up to 100℃)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port alignment: ISO 5599-1 standard (subplate mount compatible)
- Weight: 0.65 kg (1.43 lbs)
- Dimensions: 58mm(W) × 48mm(H) × 115mm(L)
- Manual override: Built-in emergency toggle switch
- Coil insulation class: Class F (155℃)
High-flow proportional control valve with dual pressure balance structure, featuring optimized spool geometry for reduced sticking risk in humid environments. The copper-free aluminum alloy body meets ISO 14001 environmental standards. Includes surge protection circuitry and LED status indicator.
- Plastic injection molding machine cylinder control
- Textile machinery tensioning systems
- Automated bottling line actuators
- CNC machine tool clamping mechanisms
- Lithium battery production line pneumatic circuits
Installation protocol:
Mount on ISO 5599-1 compliant subplate using M5 mounting screws (torque ≤1.2Nm).
Maintain 20mm clearance below valve for heat dissipation. Use AirTAC PX-17 grease
for port thread sealing. Perform weekly manual cycling in high-condensation environments.
| Property | Property Value |
|---|---|
| sku | 2KWX05010BI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
