Airtac 2KWX Fluid Solenoid Valve 2KWX05010FI
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX Fluid Solenoid Valve 2KWX05010FI Technical Details
- Model: 2KWX05010FI
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 850 L/min (Cv=1.2)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 310g ±5g (with connector)
- Dimensions: 58mm(L) × 35mm(W) × 73mm(H) (excluding fittings)
- Valve body material: Reinforced PBT with glass fiber
- Seal material: FDA-compliant FKM fluorocarbon
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.8W (DC), 3.5VA (AC)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
The 2KWX05010FI features a direct-acting design with zero pressure differential requirement, enabling reliable switching even in vacuum applications. Its corrosion-resistant construction and food-grade seals make it suitable for aggressive media. The valve incorporates copper-free aluminum alloy coils (RoHS compliant) with overcurrent protection and LED status indication.
- Chemical dosing systems (acid/alkaline solutions)
- Semiconductor wafer cleaning equipment
- Mobile hydraulic cooling circuits
- Beverage filling line liquid control
- Laboratory analytical instrument flow switching
Installation guidelines:
Mount in any orientation except coil-down position. Flush system before installation (max particle size 50μm).
For pulsating applications, install a pulsation damper 150mm downstream. Compatible with ISO VG32 hydraulic fluids
and water-glycol mixtures up to 40% concentration.
| Property | Property Value |
|---|---|
| sku | 2KWX05010FI |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC12V |
