Airtac 4A200 Pneumatic Valve 4A21008
$20.90
Regular price
$28.40
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4A21008
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Spool-type structure ensures excellent sealing performance and responsive actuation;
2、3-position pneumatic valves offer three selectable center position configurations;
3、Double pneumatic pilot 2-position valves feature memory retention capability;
4、Precision-honed internal bore minimizes friction resistance, enables low pilot pressure activation, and guarantees extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Manifold base compatibility for space-efficient system integration;
Category: Pneumatic Valves , Brand: AIRTAC , Series: 4A200
Installation guidelines:
Mount on vibration-damped surfaces. Maintain minimum 15mm clearance
below valve for exhaust airflow. Use locking adhesive on pilot tubes
(LOCTITE 243 recommended). Perform monthly manual cycling for systems
with infrequent operation.
2、3-position pneumatic valves offer three selectable center position configurations;
3、Double pneumatic pilot 2-position valves feature memory retention capability;
4、Precision-honed internal bore minimizes friction resistance, enables low pilot pressure activation, and guarantees extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Manifold base compatibility for space-efficient system integration;
Category: Pneumatic Valves , Brand: AIRTAC , Series: 4A200
AirTAC 4A200 Series 4A21008 Pneumatic Valve Technical Details
- Model: 4A21008 (4A200 series)
- Type: 5-port 2-position pneumatic directional valve
- Port configuration: 5/2-way (P, A, B, R, S)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Max flow capacity: 750 L/min (Cv=1.3)
- Actuation type: Double pilot air operated
- Response time: ≤0.1 sec (at 0.5 MPa)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Body material: Reinforced PBT with glass fiber
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Mounting: ISO 5599-1 standard subplate
- Protection rating: IP67 (dust/water resistant)
High-flow pneumatic valve with symmetrical pressure balance design for stable switching under variable loads. Features wear-resistant seals and anti-vibration structure, optimized for continuous cycling operations. Requires lubricated air (ISO VG32 or equivalent) with 50μm filtration.
Industrial Applications:
- Pneumatic cylinder control in assembly lines
- Material handling systems (stackers/separators)
- Textile machinery tension control
- Plastic injection molding machines
- Automotive tire assembly equipment
Installation guidelines:
Mount on vibration-damped surfaces. Maintain minimum 15mm clearance
below valve for exhaust airflow. Use locking adhesive on pilot tubes
(LOCTITE 243 recommended). Perform monthly manual cycling for systems
with infrequent operation.
| Property | Property Value |
|---|---|
| sku | 4A21008 |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
