Airtac 4HV Manual Rotary Valve 4HV21008SL
$34.86
Regular price
$42.36
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
4HV21008SL
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Lightweight directional switching rotation with excellent tactile feedback and precise positioning;
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
Installation note:
Apply silicone-free grease to shaft O-ring during maintenance.
Ensure proper alignment of port labels with pneumatic connections.
Maximum lateral load on handle: 15N.
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV21008SL Manual Rotary Valve Specifications
- Model: 4HV21008SL
- Type: 3-position (L-type) detent manual rotary valve
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 1,200 NL/min
- Operating temperature: -5℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Actuation torque: ≤0.5 N·m
- Weight: 250g ±5%
- Dimensions: 54mm(L) × 34mm(W) × 34mm(H)
- Mounting: Direct panel mounting with M4 screws
- Position indication: Colored sector window (Green/Orange/Red)
- Cycle life: ≥500,000 rotations
Manual override valve with positive center position lock, featuring a smooth 90° rotation arc. The chromium-plated steel shaft and wear-resistant HNBR seals ensure reliable performance in high-humidity environments. Includes tactile feedback detents and visual position confirmation.
Typical Applications:
- Emergency override in automated production lines
- Manual mode selection in plastic injection molding machines
- Pneumatic system maintenance bypass
- Educational training equipment for fluid power systems
- Mobile hydraulic platform controls
Installation note:
Apply silicone-free grease to shaft O-ring during maintenance.
Ensure proper alignment of port labels with pneumatic connections.
Maximum lateral load on handle: 15N.
| Property | Property Value |
|---|---|
| sku | 4HV21008SL |
| Position | 4-way 2-position |
| Port Size | PT1/4 |
