Airtac 6V-F Base 6V0500M14F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Base Unit 6V0500M14F Technical Specifications
- Model: 6V0500M14F
- Series: 6V-F Compact Cylinder Mounting Base
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (natural color)
- Mounting hole spacing: 50mm (±0.2mm)
- Thread specifications: M14×1.5 mounting threads
- Compatible cylinders: MAL/MAS 50mm bore series
- Mounting style: Side-mount with through-hole design
- Operating temperature: -20℃ to 80℃
- Weight: ~800g (including fasteners)
- Dimensions: 50mm(W) × 50mm(D) × 14mm(H)
- Vibration resistance: ≤49 m/s² (10-55Hz)
- Corrosion resistance: 96hrs salt spray test passed
Precision-machined mounting base designed for stable cylinder fixation in high-cycle applications. Features anti-loosening thread design with integrated vibration dampening grooves. Includes stainless steel M14×45 hex socket screws pre-installed with copper anti-seize compound for maintenance-free operation.
- Robotic arm end-effector mounting
- High-speed pick-and-place automation lines
- Semiconductor wafer handling systems
- Packaging machine vertical lift mechanisms
- Food processing equipment (FDA-compliant grease option available)
Installation note:
Apply 3.5-4.5N·m torque during assembly. Use shim washers when mounting
on uneven surfaces. For vertical installations, apply thread locker
to lower two fasteners. Compatible with ISO 21287 standard cylinders.
- Re-torque after first 50,000 cycles
- Clean with alkaline detergent (pH 7-9) only
- Inspect groove channels quarterly for debris accumulation
| Property | Property Value |
|---|---|
| sku | 6V0500M14F |
