Airtac 6V-F Base 6V0500M2F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V0500M2F Technical Specifications
- Model: 6V0500M2F
- Series: 6V-F Standard Mounting Base
- Compatible Cylinder Bore Size: φ50mm (SC Series Standard Cylinders)
- Mounting Type: ISO 15552 Standard Foot Mount
- Material: Aluminum Alloy ADC12
- Surface Treatment: Anodized (Silver) + Phosphate Coating
- Mounting Hole Spacing: 50mm ±0.2 (Center-to-Center)
- Thread Specifications: M6×1.0 Internal Thread (4 Holes)
- Operating Temperature: -20℃ to +80℃
- Static Load Capacity: ≤980N
- Dynamic Load Capacity: ≤490N
- Weight: 0.82kg ±3%
- Dimensions: 100mm(L) × 50mm(W) × 25mm(H)
- Parallelism Tolerance: ≤0.1mm
- Surface Roughness: Ra3.2μm
Precision-engineered mounting base with dual-stage surface treatment for enhanced corrosion resistance in humid environments. Features CNC-machined locating surfaces (flatness ≤0.05mm) and counterbored mounting holes to prevent bolt head protrusion. Compatible with SC/SU/SI series cylinders when used with adapter kits.
- Fixed mounting of vertical actuators in packaging machinery
- Modular assembly systems for automotive production lines
- Precision positioning stages in semiconductor handling equipment
- Vibration-damped installations for food processing conveyors
Installation protocol:
Use Class 8.8 or higher fasteners with Loctite 243 threadlocker.
Ensure base surface cleanliness (≤0.5μm particulate) before cylinder mounting.
Torque M6 bolts to 5.5-6.5N·m using crisscross pattern tightening sequence.
