Airtac 6V-F Base 6V100M10F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Unit 6V100M10F Technical Details
- Model: 6V100M10F (6V-F Series Modular Base)
- Valve compatibility: For 10mm width solenoid valves
- Port configuration: 5 ports (P, A, B, R1, R2)
- Thread size: G1/8 (ISO228 standard)
- Max operating pressure: 1.0 MPa
- Flow capacity: 750 L/min (ANR)
- Weight: 220g ±5% (bare base without valves)
- Dimensions: 100mm(L) × 32mm(W) × 32mm(H)
- Mounting pitch: 10mm between valve slots
- Material: Glass fiber reinforced PA66
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Surface treatment: Anti-corrosion anodizing
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Modular aluminum alloy base designed for multi-valve manifold systems, featuring integrated air passageways for reduced piping complexity. The T-slot design enables tool-free valve assembly and supports up to 10 valve positions in series. Includes builtin silencer pockets and standardized mounting patterns for DIN rail or direct panel installation.
- Automated assembly line control clusters
- Plastic injection molding machine manifolds
- Textile machinery pneumatic circuits
- Semiconductor handling equipment
- Multi-axis robotic end effector controls
Installation guidelines:
Apply thread sealant only on male ports (not manifold surface).
Tighten mounting screws diagonally to 0.4-0.6 N·m torque.
Use M5x8mm stainless steel screws for valve attachment.
| Property | Property Value |
|---|---|
| sku | 6V100M10F |
