Airtac 6V-F Base 6V100M13F
$27.21
Regular price
$34.71
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6V100M13F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enables modular integration of directional control valves from the same series into valve banks, achieving space optimization and cost efficiency;
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
Installation protocol:
Use torque-controlled screwdriver (0.6-0.8Nm) for manifold stacking.
Apply thread sealant only on middle modules - end plates require dry mounting.
Maximum 12-unit continuous manifold length recommended.
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Unit 6V100M13F Technical Details
- Model designation: 6V100M13F
- Series: 6V-F modular valve base
- Valve compatibility: For 1/4" (6V1 series) solenoid valves
- Port configuration: 3-port (P, A, R)
- Port thread size: G1/8 (ISO228 standard)
- Body material: Glass fiber reinforced PA66
- Seal material: Nitrile rubber (NBR)
- Max operating pressure: 0.9 MPa
- Temperature range: -5℃ to 80℃
- Mounting pitch: 13mm (critical for multi-valve alignment)
- Weight: 72g ±2g
- Dimensions: 100mm(L) × 22mm(W) × 32mm(H)
- Surface finish: Anti-corrosion coating (RAL 7011)
- Vibration resistance: ≤10Hz with 1.5mm amplitude
Precision-engineered modular base for creating compact valve manifolds, featuring integrated air passageways for simplified piping. The staggered port design prevents tool interference during manifold assembly. Includes built-in silencer pockets and standardized DIN rail compatibility.
Implementation Scenarios:
- Multi-valve control stations in beverage filling lines
- Robotic arm end-effector pneumatic clusters
- Textile machinery air circuit distribution blocks
- Semiconductor handling equipment manifold systems
- Bus-style pneumatic networks in automotive assembly
Installation protocol:
Use torque-controlled screwdriver (0.6-0.8Nm) for manifold stacking.
Apply thread sealant only on middle modules - end plates require dry mounting.
Maximum 12-unit continuous manifold length recommended.
| Property | Property Value |
|---|---|
| sku | 6V100M13F |
