Airtac 6V-F Base 6V100M16F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V100M16F Technical Specifications
- Model: 6V100M16F (6V-F Series)
- Type: Modular valve manifold base
- Port configuration: 1-inlet (P) + 16 outlets
- Port thread size: G1/8 (BSPP) / Optional NPT1/8
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Anodized blue finish
- Operating pressure: 0.2–0.8 MPa
- Max flow rate: 700 L/min (ANR)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 80℃
- Mounting torque: 25-30 N·m (for valve fixation)
- Weight: 850g ±2%
- Dimensions: 100mm(L) × 80mm(W) × 40mm(H)
- Compatibility: Designed for 6V1/6V2 series valves
- Protection rating: IP40 (when valves installed)
High-density modular base with integrated flow channels, engineered for multi-valve clustering in compact installations. Features precision-machined sealing surfaces with leak-proof design and anti-vibration grooves. The T-slot mounting system allows tool-free valve attachment and supports horizontal/vertical stacking configurations.
- Centralized pneumatic control panels
- Automated assembly line valve clusters
- Robotic end-effector manifold systems
- Packaging machinery multi-actuator control
- Semiconductor handling equipment
Installation protocol:
Apply thread sealant (PTFE tape excluded) on port connections.
Use torque wrench for even valve mounting.
Perform pressure decay test (≤0.1MPa drop in 5min) after assembly.
