Description
1. Enables modular integration of directional control valves from the same series into valve banks, achieving space optimization and cost efficiency;
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
Installation protocol:
Torque mounting screws to 0.8-1.2N·m in crisscross pattern.
Apply silicone-free grease (Molykote 111 recommended) to manifold
contact surfaces before stacking. Maintain 50mm clearance below
for service access.
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Unit 6V100M18F Technical Details
- Model: 6V100M18F
- Type: Modular pneumatic valve base (ISO 15407-1 compliant)
- Mounting Interface: M18×1.5 threaded connection
- Port Configuration: 5/2-way function compatible
- Port Size: G1/8 (BSPP) with 4.8mm orifice diameter
- Max Operating Pressure: 1.0 MPa (10 bar)
- Min Operating Pressure: 0.15 MPa (1.5 bar)
- Flow Capacity: 850 L/min (ANR, at 0.5 MPa)
- Seal Material: HNBR (Hydrogenated Nitrile) for oil resistance
- Temperature Range: -10℃ to 80℃ (with silicone seals optional for -20℃)
- Body Material: Reinforced PA66 with glass fiber
- Weight: 230g ±5% (without manifold or valves)
- Dimensions: 76mm(L) × 34mm(W) × 45mm(H) (manifold mounting surface to top)
- Repeat Accuracy: ±0.5% F.S.
- Vibration Resistance: 10-55Hz with 1.5mm amplitude
- Shock Resistance: 100m/s² (3 times each axis)
High-flow modular base unit designed for multi-valve stacking in compact pneumatic systems. Features dual O-ring sealing for leak-free manifold connections and corrosion-resistant nickel-plated brass inserts. The staggered port design reduces interference during tubing installation.
Industrial Applications:
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers requiring multi-cylinder control
- Food packaging equipment with frequent valve replacement needs
- Robotic end-effector pneumatic circuits
Installation protocol:
Torque mounting screws to 0.8-1.2N·m in crisscross pattern.
Apply silicone-free grease (Molykote 111 recommended) to manifold
contact surfaces before stacking. Maintain 50mm clearance below
for service access.
Valve Compatibility:
Interfaces with 6V1/6V2 series solenoid valves and 6V-□-M18F
pressure switches. Requires 6V-MB series manifold blocks for
multi-station configurations.
| Property | Property Value |
|---|---|
| sku | 6V100M18F |
