Airtac 6V Solenoid Valve 6V0510M5A200
$29.06
Regular price
$36.56
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6V0510M5A200
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Plug-in electrical connection with interchangeable horizontal/vertical terminal orientation;
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
Installation note:
Mount with DIN rail adapter (optional 6V-RA01) or direct panel mounting.
Use thread sealant on port connections (PTFE tape not recommended).
Allow 15mm clearance below valve for connector access.
Critical parameter:
Minimum holding voltage 85% of rated voltage.
Do not use with pulsating pressure above 1.2MPa peak.
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510M5A200 Solenoid Valve Specifications
- Model: 6V0510M5A200
- Type: 5/2-way single solenoid (monostable)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Flow coefficient (Cv): 0.75
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 250g ±5% (without connector)
- Dimensions: 50mm(L) × 40mm(W) × 70mm(H)
- Seal material: FKM (Viton®) for high temp applications
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Power consumption: ≤2.2W (DC), ≤3.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 9.5mm (minimum engagement)
- Max operating frequency: 5Hz (cyclic duty)
High-flow 5-port pneumatic valve with manual override, designed for bidirectional cylinder control. Features aluminum alloy body with hard anodized finish and zero-pressure differential activation. Requires ISO 8573-1:2010 Class 3-4-3 compressed air (max 50mg/m³ oil content).
Typical Applications:
- Factory automation cylinder sequencing
- Textile machinery clamp controls
- Bottle filling station actuators
- Plastic injection molding ejectors
- Automotive assembly line tooling
Installation note:
Mount with DIN rail adapter (optional 6V-RA01) or direct panel mounting.
Use thread sealant on port connections (PTFE tape not recommended).
Allow 15mm clearance below valve for connector access.
Critical parameter:
Minimum holding voltage 85% of rated voltage.
Do not use with pulsating pressure above 1.2MPa peak.
| Property | Property Value |
|---|---|
| sku | 6V0510M5A200 |
| Port Size | M5 |
| Standard Voltage | AC220V |
