Airtac 6V Solenoid Valve 6V230C06B200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V230C06B200 Solenoid Valve Technical Details
- Model Code Breakdown: 6V230C06B200
- 6V: 6-port valve series
- 230: 2-position 3-way function
- C: Coil protection class (IP65)
- 06: 1/4" BSPP port size
- B: AC/DC universal coil
- 200: 24VDC voltage specification
- Valve Type: 5/2-way double pilot operated
- Port Thread: G1/4 (ISO228 standard)
- Operating Pressure Range: 0.1-1.0 MPa (14.5-145 PSI)
- Voltage Tolerance: ±10% (21.6-26.4VDC)
- Power Consumption: 2.2W (at 24VDC)
- Response Time: ≤25ms (pressurized to full flow)
- Flow Capacity: 1200Nl/min (Cv=1.8)
- Seal Material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Ambient Temperature: -5℃ to 60℃ (with condensation prevention)
- Weight: 480g ±5% (including coil assembly)
- Dimensions: 62mm(W) × 45mm(H) × 98mm(L)
- Mounting: ISO 15407-1 standard sub-base compatible
- Electrical Connection: DIN43650 Form A connector
High-flow directional control valve with dual pressure pilot operation, featuring brass alloy body construction with hard-anodized aluminum end caps. Designed for heavy-duty pneumatic systems requiring rapid cycling (up to 5Hz). Includes manual override button for system debugging and emergency operation. Requires 5-40μm filtered compressed air with lubricator (ISO8573-1 class 4).
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC machine tool chuck controls
- Automotive brake system testing rigs
- Bottle capping/palletizing systems
Installation guidelines:
Mount horizontally with pilot ports facing downward to prevent condensate accumulation.
Use copper-free anti-seize compound on threaded ports. Maintain minimum 20mm clearance
around valve body for heat dissipation. Ground the metal manifold when used in ESD-sensitive environments.
- Mechanical durability: 50 million cycles
- Coil insulation class: F (155℃)
- Recommended maintenance: Inspect seals every 10M cycles, replace pilot filter every 6 months
