Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X10-10
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X10-10 Adjustable Compact Cylinder Specifications
- Model: ACEJ125X10-10
- Type: Double-acting adjustable compact cylinder
- Bore size: 125mm
- Stroke: 10mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable elastic cushion (both ends)
- Piston speed: 50–1000 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: G1/4 (ISO standard)
- Mounting type: Basic (optional flange/bracket kits available)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid
- Weight: 2.85 kg (±2%)
- Dimensions: 180mm(L) × 145mm(W) × 145mm(H) (at mid-stroke)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (maintenance-free for 5000km stroke)
The ACEJ125X10-10 features dual-axis adjustability with micrometer-style stroke adjustment screws (±5mm range). Its compact profile integrates a built-in magnet for position sensing compatibility. The double labyrinth seal design enhances dust resistance while maintaining low friction (≤0.15 dynamic friction coefficient). Requires 5μm filtered air with ISO VG32-grade oil mist lubrication recommended for heavy cycling.
- Precision press-fitting operations in automotive assembly
- Variable height positioning in semiconductor wafer handling
- Clamping force adjustment in CNC fixture systems
- Packaging line product ejection with force control
- Robotic end-effector tooling requiring space optimization
Installation tip:
Align cylinder axis within 0.2mm perpendicularity tolerance. For vertical mounting,
use counterbalance valves when handling loads >15kg. Allow 25mm clearance
behind adjustment screws for maintenance access.
Critical note:
Stroke adjustment must be performed with cylinder depressurized.
Exceeding 1.0 MPa may compromise cushioning effectiveness.
Annual seal inspection recommended for >500,000 cycle applications.
| Property | Property Value |
|---|---|
| sku | ACEJ125X10-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | <10mm> |
