Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-10 Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-10
- Type: Double-acting adjustable compact cylinder
- Bore size: 125mm
- Stroke: 100mm (±1mm adjustable)
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Mounting style: Basic type (no built-in mounts)
- Port size: G1/8 (ISO standard)
- Weight: 5.2kg (excluding accessories)
- Dimensions: 300mm(L) × 140mm(W) × 140mm(H)
- Rod material: Chrome-plated steel
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 80℃
- Protection rating: IP40 (dust protected)
- Piston speed: 50–800 mm/s (lubricated)
High-precision industrial cylinder featuring micro-stroke adjustability (±1mm) through its unique dual-locknut design. The corrosion-resistant anodized body and hybrid seals enable reliable operation in humid environments. Optimized for applications requiring precise end-position control without external stoppers.
- Automated press-fit systems for electronics assembly
- Palletizing robot end-effector positioning
- Textile machinery tension control units
- Automotive welding fixture clamping
- Packaging line product ejection mechanisms
Installation note:
For optimal performance, maintain 0.5–1mm clearance between adjustable stoppers during calibration.
Use locknuts with 1.5–2.5N·m torque. Requires 40μm filtered air with ISO VG32 lubricant.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
