Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-100
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-100 Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-100
- Type: Double-acting adjustable stroke compact cylinder
- Bore size: Ø125mm
- Stroke: 100mm (adjustable range: ±5mm)
- Operating pressure: 0.1-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (front/rear)
- Port size: G1/2 (NPT1/2 optional)
- Piston speed: 50-800 mm/s
- Ambient temperature: -20℃ to +80℃
- Lubrication: Pre-lubricated (NBR seals)
- Mounting style: Basic type (MF1) with optional foot mounting
- Material: Aluminum alloy barrel, hardened steel piston rod
- Weight: 5.2 kg (bare cylinder), 5.8 kg (with accessories)
- Dimensions: 300mm(L) × 125mm(W) × 125mm(H)
- Rod thread: M20×1.5 external thread
- Protection class: IP54 (standard), IP67 (optional)
High-precision compact cylinder featuring stroke adjustment mechanism with ±5mm fine-tuning capability through integrated locknuts. The double-wall aluminum construction ensures heat dissipation while maintaining 25% lighter weight than standard cylinders. Includes wear-resistant guide bands and shock-absorbing bumpers for 10 million cycle durability. Requires 40μm filtered air with ISO VG32 hydraulic oil mist lubrication (optional oil-free operation).
- Press machine die height adjustment systems
- Automated packaging line stopper mechanisms
- Plastic injection molding ejector units
- Warehouse sorting shuttle positioning
- Semiconductor wafer handling equipment
Installation tip:
For vertical installations exceeding 45° angle, use the auxiliary mounting brackets (sold separately).
Maintain 0.5mm minimum clearance between rod end and load during alignment. Lubricate guide shafts every
5,000km of cumulative travel distance.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-100 |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
