Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10S
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-10S Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-10S
- Type: Adjustable stroke, single-acting spring return
- Bore size: Φ125mm
- Stroke: 100mm (adjustable ±1mm via external screw)
- Operating pressure: 0.1–1.0 MPa
- Medium: Dry air (lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper
- Mounting type: Basic (standard) with optional foot/axial mounts
- Port size: G1/2 (BSPP thread)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel
- Seal material: NBR (nitrile rubber)
- Weight: 2.5kg ±3%
- Dimensions: 235mm(L) × 138mm(W) × 138mm(H) (at full extension)
- ISO standard: 6432 compliant
High-precision compact cylinder featuring external stroke adjustment capability through a 360° rotatable screw mechanism. The aluminum construction reduces inertia while maintaining structural rigidity, with integrated magnetic field for sensor compatibility. Includes dual cushioning system with locknut adjustment for precise end-position deceleration.
- Space-constrained automation lines requiring stroke fine-tuning
- Packaging machinery with variable product sizes
- Electronics assembly positioning systems
- Automotive fixture clamping mechanisms
- Textile machinery tension control
Installation note:
For optimal performance, maintain 0.5-1mm clearance between cylinder body and machine frame.
Lubricate rod end weekly with ISO VG32 hydraulic oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
