Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-10SB
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-10SB Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-10SB
- Type: Double-acting adjustable compact cylinder
- Bore size: Ø125mm
- Stroke: 100mm (customizable 50-300mm)
- Mounting style: Basic foot (ISO 15552 standard)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/2 (BSPP thread)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 3.8kg ±2%
- Dimensions: 230mm(L) × 125mm(W) × 165mm(H)
- Sensor slots: 2x T-slot (for magnetic switches)
- Rod end thread: M16×1.5 (external)
- Protection rating: IP54 (standard)
High-efficiency compact cylinder featuring dual adjustable air cushions and precision machined guide surfaces. The optimized flow path design achieves 15% faster cycle times compared to standard models. Integrated wear-resistant bands ensure smooth operation up to 2,000km service life. Compatible with ISO 15552 mounting accessories.
- High-speed packaging machine ejectors
- Automotive welding fixture positioning
- Plastic injection molding clamp units
- Material handling transfer systems
- Elevator door operation mechanisms
- Press tooling alignment devices
Installation tip:
Maintain 0.5-1mm alignment tolerance during mounting. Use locknuts with
maximum 20N·m torque. For vertical installations, add lubricator to air supply
(ISO VG32 recommended). Replace seals after 5 million cycles or 3 years.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
