Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-20
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-20 Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-20
- Type: Double-acting adjustable stroke cylinder
- Bore size: 125mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange with adjustable mounting positions
- Port size: G1/2 (ISO standard)
- Temperature range: -20℃ to 80℃
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 3.8kg ±2%
- Dimensions:
- Extended length: 307mm
- Retracted length: 207mm
- Body diameter: 125mm
- Mounting flange width: 160mm
High-precision industrial cylinder featuring micro-stroke adjustability (±0.5mm) through integrated locknuts. The wear-resistant design incorporates dual guide rods for enhanced lateral load capacity (max 150N·m). Includes magnetic piston for position sensing compatibility. Operates at speeds up to 1.5m/s with proper cushioning adjustment.
- Precision clamping in CNC machine tooling
- Vertical lifting mechanisms in automated warehouses
- Press-fit operations in automotive assembly lines
- Packaging machine stopper positioning
- Plastic injection molding ejector systems
Installation note:
Maintain 0.5-1mm clearance between cushion screws and end caps during adjustment.
Lubricate rod threads with ISO VG32 hydraulic oil monthly. Avoid side load exceeding
10% of maximum thrust capacity.
Requires 5μm filtered air with
lubrication (oil mist 1 drop/m³). Do not disassemble cushion mechanism without
torque wrench (recommended 4.5N·m).
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-20 |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
