Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-20S
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-20S Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-20S
- Type: Double-acting adjustable stroke compact cylinder
- Bore size: 125mm
- Stroke: 100mm (adjustable ±3mm)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer (front/rear)
- Mounting type: Standard ISO/VDS 24mm (alternative mountings available)
- Port size: G3/8 (NPT1/4 optional)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (nitrile) with wear-resistant ring
- Weight: 5.8kg ±2%
- Dimensions: 282mm(L) × 125mm(W) × 125mm(H)
- Rod thread: M20×1.5 (external)
- Protection rating: IP54 (standard wiper)
- Lubrication: Pre-lubricated (recommended relubrication every 200km stroke)
High-efficiency compact cylinder featuring precision-adjustable stroke and cushioning for space-constrained industrial applications. The reinforced aluminum alloy body with chrome-plated piston rod provides exceptional corrosion resistance. Unique T-slot mounting design allows flexible installation orientations. Optional magnetic version (add "-M" suffix) available for position sensing.
- Automated assembly line clamping mechanisms
- Textile machinery tension control systems
- Plastic injection molding ejectors
- Automotive welding fixture positioning
- Food processing press actuators (food-grade lubrication option)
Installation note:
For vertical mounting, install lock nuts on piston rod threads.
Maintain 0.5–1mm clearance between adjustable stopper and cylinder
end for thermal expansion. Lubricate through air port using ISO VG32
pneumatic oil during maintenance.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
