Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-20SB
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-20SB Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-20SB
- Type: Adjustable stroke double-acting cylinder
- Bore size: Φ125mm
- Stroke: 100mm (adjustable ±2mm)
- Operating pressure: 0.05–1.0 MPa
- Medium: Clean compressed air (lubricated/non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable screw
- Mounting type: SB series basic mounting (ISO 15552 standard)
- Port size: G3/8
- Piston speed: 50–750 mm/s
- Weight: 4.8 kg (with standard accessories)
- Dimensions: 228mm(L) × 165mm(W) × 165mm(H)
- Rod thread: M20×1.5
- Protection rating: IP65 (standard wiper seal)
- Material: Aluminum alloy body, chrome-plated piston rod
High-precision adjustable cylinder featuring dual-position locking mechanism with visual stroke indicators. The triple-seal design (rod seal, buffer seal, and wiper seal) ensures exceptional leakage prevention. Compatible with magnetic sensors (sensor slot included). Includes anti-rotation guide for stable linear motion.
- Precision clamping fixtures in CNC machining centers
- Variable height positioning in automotive assembly lines
- Material handling systems requiring stroke adjustments
- Packaging machinery with space constraints
- Plastic injection mold ejection mechanisms
Installation note:
Lubricate piston rod with ISO VG32 hydraulic oil before initial use.
For vertical mounting, install locking nut (not included) on rod end.
Maintain 30mm clearance behind cylinder for stroke adjustment tools.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-20SB |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
