Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-30
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-30 Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-30
- Type: Double-acting adjustable cushion cylinder
- Bore size: 125mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: G1/2 (BSPP thread)
- Piston speed: 50-750 mm/s (lubricated)
- Ambient temperature: -20℃ to 80℃
- Weight: 2.65 kg (excluding accessories)
- Dimensions: 212mm(L) × 125mm(W) × 125mm(H)
- Rod thread: M20×1.5 (external)
- Mounting type: Basic type (no built-in mounts)
- Seal material: NBR + PU combination
- Protection rating: IP65 (dust/water jet resistant)
High-torque compact cylinder featuring precision-machined aluminum alloy body with chromed piston rod (hardness HRC 45-50). The twin-cushion design allows 25% greater impact absorption than standard models. Integrated anti-rotation mechanism ensures stable linear motion in high-cycle applications. Pre-lubricated for immediate use with ISO VG32 hydraulic oil compatibility.
- Material handling gate actuators
- Plastic injection molding ejectors
- Automated palletizing systems
- Textile machinery tension control
- Food processing press mechanisms
Installation note:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use locknuts on piston rod threads. Lubricate every 5,000km of cumulative stroke
movement under normal conditions.
Critical parameters:
Maximum side load 280N, axial load 1,850N. Do not exceed 80% of maximum pressure
when using angular brackets. Requires 5μm filtration for optimal seal life.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-30 |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
