Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-30SB
$237.25
Regular price
$244.75
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ125X100-30SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 21287 standard for enhanced mounting dimension compatibility;
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
Installation note:
For optimal performance, maintain 0.5mm alignment tolerance during mounting.
Adjust cushioning screws while observing actual stroke movement.
Use AIRTAC TAC-01 pneumatic grease when operating below -10℃.
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-30SB Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-30SB
- Type: Double-acting adjustable compact cylinder with built-in cushioning
- Bore size: Ø125mm
- Stroke: 100mm (adjustable ±3mm)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: External adjustable rubber buffer + internal air cushion
- Port size: PT1/4 (G1/4 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Body material: Aluminum alloy (A6063-T5)
- Seal material: NBR (Nitrile rubber)
- Mounting type: Standard foot-mounted (ISO 15552 compatible)
- Weight: 3.5 kg (without accessories)
- Dimensions: 300mm(L) × 140mm(W) × 140mm(H) (at mid-stroke position)
- Rod thread: M16×1.5
- Lubrication: Pre-lubricated (Oil-free operation possible)
A space-saving pneumatic solution combining high thrust capacity (up to 1,227N at 0.7MPa) with precision stroke adjustment. Features dual cushioning system for smooth end-of-stroke deceleration and reduced impact noise. The anodized surface treatment provides enhanced corrosion resistance for harsh environments.
Typical Applications:
- High-speed press machine ejection systems
- Automated conveyor gate actuators
- Plastic injection molding machine clamping units
- Heavy-duty material handling equipment
- Automotive assembly line positioning devices
Installation note:
For optimal performance, maintain 0.5mm alignment tolerance during mounting.
Adjust cushioning screws while observing actual stroke movement.
Use AIRTAC TAC-01 pneumatic grease when operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-30SB |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
