Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-40S
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-40S Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-40S
- Type: Adjustable stroke compact pneumatic cylinder
- Bore size: Φ125mm
- Stroke: 100mm (adjustable ±2mm via external stop screws)
- Mounting type: Basic front flange (ISO 15552 standard)
- Cushioning: External adjustable rubber buffer + shock absorber
- Operating pressure: 0.15–1.0 MPa
- Temperature range: -20℃ to 80℃
- Piston material: Anodized aluminum alloy
- Rod material: Hard chrome-plated stainless steel (SUS304)
- Seal type: NBR wear-resistant seals
- Port size: G3/8 (M14×1.5 thread optional)
- Weight: 6.5kg ±3% (excluding accessories)
- Dimensions: 250mm(L) × 128mm(W) × 128mm(H)
- Rod end type: Female thread M20×1.5
- Protection rating: IP65 (standard wiper design)
High-precision industrial cylinder featuring a unique dual-axis stroke adjustment mechanism and anti-rotation piston rod. The aluminum alloy body with chrome-plated guide sleeve ensures smooth operation in high-cycle applications (up to 5 million cycles). Includes magnetic piston for position sensing compatibility. Designed for ISO 15552 mounting patterns with 40mm spacing between mounting holes.
- Precision positioning in robotic assembly lines
- Clamping fixtures for CNC machining centers
- Material handling in tight factory spaces
- Packaging machine pusher mechanisms
- Automated door locking systems
Installation tip:
For optimal performance, maintain 0.5-1mm clearance between adjustable stoppers during setup.
Lubricate rod weekly with ISO VG32 hydraulic oil in high-humidity environments.
Critical note:
Maximum side load capacity 350N. Avoid angular misalignment exceeding ±2° during mounting.
Use shock absorber oil (ISO VG15-22) when operating at full stroke >800mm/s.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
