Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-40SB
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-40SB Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-40SB
- Type: Adjustable stroke, double-acting cylinder
- Bore size: 125mm
- Stroke: 100mm (adjustable ±2mm)
- Mounting style: SB-type foot mounting
- Buffer type: Adjustable hydraulic cushioning
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: G3/8 (NPT1/2 optional)
- Rod thread: M40×1.5
- Seal material: Polyurethane (NBR option available)
- Protection rating: IP54 (standard)
- Weight: 3.8kg ±5%
- Dimensions: 230mm(L) × 135mm(W) × 143mm(H)
High-precision industrial cylinder featuring dual-axis adjustability with mechanical lock mechanism. The hardened stainless steel piston rod and aluminum alloy barrel ensure durability in high-cycle applications. Integrated shock absorption system reduces end-impact noise by 15dB compared to standard models.
- Precision positioning in robotic welding fixtures
- Material handling systems requiring stroke adjustment
- Plastic injection molding machine ejectors
- Automated assembly line clamping units
- Textile machinery tension control mechanisms
Installation note:
Lubricate rod end threads with MIL-PRF-81322 grease before adjustment.
Maintain 0.5mm minimum clearance between cushion lock nuts for thermal expansion.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-40SB |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
