Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-50 Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-50
- Type: Adjustable stroke compact pneumatic cylinder
- Bore size: Ø125mm
- Stroke: 100mm (adjustable within 50-150mm range)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable elastic cushioning at both ends
- Mounting style: Standard foot-mounted (MF1) with optional front flange
- Port size: G1/2 (BSPP thread)
- Operating temperature: -20℃ to 80℃
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 4.8kg (dry, without accessories)
- Dimensions:
- Length (retracted): 247mm
- Length (extended): 347mm
- Body width: 156mm
- Height (including mounting foot): 165mm
- ISO standard: 6432 (compact cylinder series)
The ACEJ125X100-50 features a space-saving design with 35% reduced installation space compared to standard cylinders. Its dual-axis adjustable stroke mechanism allows precise positioning through integrated stroke adjustment screws (±2mm fine-tuning capability). The cylinder incorporates wear-resistant guide bands and a built-in magnet for position sensing compatibility.
- Precision clamping fixtures in CNC machining centers
- Vertical lift mechanisms for packaging line diverters
- Press machine ejection systems with variable stroke requirements
- Automated warehouse stacker positioners
- Plastic injection molding machine core pullers
Installation note:
Lubricate piston rod with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5mm minimum clearance between adjustment screws and mechanical stops.
For vertical installations, use tandem cylinders or external guides when handling >200kg loads.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-50 |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
