Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-50S
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-50S Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-50S
- Type: Double-acting adjustable compact cylinder
- Bore size: 125mm
- Stroke: 100mm (±0.5mm adjustment range)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: External adjustable rubber buffer
- Mounting style: Standard foot mounting (ISO 15552 compatible)
- Port size: G1/2 (BSPP thread)
- Operating temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodized surface
- Rod material: Chrome-plated steel (Cr equivalent ≥0.8μm)
- Seal material: NBR/PU compound seals
- Weight: 3.8kg (excluding accessories)
- Dimensions: 260mm(L) × 150mm(W) × 150mm(H)
- Protection rating: IP54 (standard wiper configuration)
- Lubrication: Pre-lubricated (DIN 51503 VDL/VGL)
High-precision industrial cylinder featuring dual-position stroke adjustment through integrated locknuts. The corrosion-resistant design incorporates wear-compensating seals and impact-absorbing end caps. Includes magnetic piston for position sensing compatibility. Minimum operating pressure of 0.05MPa enables low-energy applications.
- Precision press mechanisms in automotive assembly
- Variable-height positioning in CNC material handling
- Packaging line gate control with space constraints
- Plastic injection molding ejection systems
- Semiconductor wafer transfer equipment
Installation note:
Requires 0.5Nm torque for cushion adjustment screws. For vertical mounting,
use auxiliary rod-end support. Lubricate every 3,000km operation or 6 months
with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
