Airtac ACEJ125 Adjustable Compact Cylinder ACEJ125X100-75
$232.60
Regular price
$240.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ125X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 21287 standard for enhanced mounting dimension compatibility;
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
Installation tip:
For optimal performance, adjust cushion screws while cylinder is pressurized.
Always complete final torque tightening (12-15Nm) after stroke adjustment.
Lubricate rod weekly in high-cycle applications (>500 cycles/day).
2. Threaded body-end cover connection ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and durability;
4. Asymmetrical bidirectional piston sealing design optimizes space efficiency while integrating oil retention functionality;
5. Compact architecture reduces installation footprint by 50% compared to ISO 15552 cylinders of equivalent bore size;
6. Triple-side sensor grooves on cylinder body enable flexible sensor mounting;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for versatile configuration.
Category: Adjustable Cylinders , Brand: AirTAC , Series: ACEJ125
AirTAC ACEJ125X100-75 Adjustable Compact Cylinder Specifications
- Model: ACEJ125X100-75
- Type: Adjustable stroke compact pneumatic cylinder
- Bore size: 125mm
- Stroke: 100mm (±5mm adjustable)
- Adjustment range: 75mm total (front/rear adjustable collars)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Basic fixed type (MF1) with front flange
- Port size: PT1/2 (G1/2 optional)
- Operating temperature: -20℃ to 80℃
- Piston material: Hard anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal type: NBR wear-resistant seals
- Weight: 4.8kg (without accessories)
- Dimensions: 312mm(L) × 125mm(W) × 125mm(H)
- Protection rating: IP54 (standard wiper design)
High-precision industrial cylinder featuring dual adjustable mechanical stops for precise stroke control. The compact profile combines with large bore size for significant force generation (up to 1,227N @0.63MPa). Enhanced rod guidance system reduces lateral load stress, making it ideal for misalignment-prone applications.
Typical Applications:
- Variable-height positioning in automated assembly lines
- Press-fit operations in electronic component manufacturing
- Material handling with controlled deceleration
- Packaging machine stopper mechanisms
- Plastic injection molding ejector systems
Installation tip:
For optimal performance, adjust cushion screws while cylinder is pressurized.
Always complete final torque tightening (12-15Nm) after stroke adjustment.
Lubricate rod weekly in high-cycle applications (>500 cycles/day).
| Property | Property Value |
|---|---|
| sku | ACEJ125X100-75 |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/4" Thread |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
