Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X10-10
$57.45
Regular price
$64.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X10-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation recommendation:
For vertical mounting applications exceeding 0.5m/s piston speed,
use external shock absorbers. Maintain 0.5mm minimum clearance
between magnetic sensor and cylinder body for reliable detection.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X10-10 Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Adjustable Compact Cylinder
- Model: ACEJ50X10-10
- Bore size: 50mm
- Stroke: 10mm (Adjustable through built-in stroke limiter)
- Operating pressure: 0.1~0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/8 (M5 optional)
- Mounting type: Basic type (ISO 15552 standard)
- Rod thread: M10×1.25
- Piston speed: 50~800 mm/s
- Seal material: NBR (Nitrile rubber)
- Cylinder material: Aluminum alloy tube, hard anodized
- Weight: 1.8kg ±5%
- Dimensions: 155mm(L) × 50mm(W) × 50mm(H) (Stroke extended)
- Protection rating: IP40 (Dust protected)
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision compact cylinder featuring a space-saving design with 25% reduced length compared to standard cylinders. The double-rod structure enhances stability during high-speed operations, while the adjustable stroke mechanism allows micro-positioning down to ±0.5mm accuracy. Integrated magnetic sensor slots (M5x0.8) enable position feedback compatibility.
Ideal Applications:
- Precision clamping in CNC tool changers
- Material handling in semiconductor wafer production
- Position adjustment in automated optical inspection (AOI) systems
- Packaging line product ejection mechanisms
- Medical device assembly automation
Installation recommendation:
For vertical mounting applications exceeding 0.5m/s piston speed,
use external shock absorbers. Maintain 0.5mm minimum clearance
between magnetic sensor and cylinder body for reliable detection.
Service life:
5,000km travel distance or 10 million cycles (whichever comes first)
under standard operating conditions (0.5MPa, 20℃, clean dry air)
| Property | Property Value |
|---|---|
| sku | ACEJ50X10-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <10mm> |
