Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X10-10B
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X10-10B Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Compact Series
- Full model: ACEJ50X10-10B
- Bore size: Ø50mm
- Stroke: 10mm (adjustable through built-in stopper)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber bumper (both ends)
- Port size: Rc1/4 (NPT1/4 optional)
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Piston rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination
- Mounting type: Basic foot mounting (ISO15552 standard)
- Protection rating: IP54 (standard dust/moisture resistance)
- Weight: 0.85kg (excluding accessories)
- Dimensions: 125mm(L) × 50mm(W) × 50mm(H)
Space-optimized linear actuator featuring 360° adjustable stroke mechanism with ±0.5mm repeat positioning accuracy. Integrated magnetic sensor groove (compatible with M9/M12 proximity sensors). Corrosion-resistant design with self-lubricating bushings reduces maintenance frequency. Requires 40μm filtered compressed air with ISO VG32 lubricant (optional oil-free operation).
- PCB assembly line clamping mechanisms
- Automated packaging machine pushers
- Medical device positioning systems
- Robotic end-effector tool changers
- Semiconductor wafer handling equipment
Installation notes:
(1) Maximum side load ≤15% of theoretical thrust
(2) Lubricate through air supply (0.5–1.0 cSt oil viscosity recommended)
(3) Allow 0.3–0.5mm thermal expansion gap in high-cycle applications
| Property | Property Value |
|---|---|
| sku | ACEJ50X10-10B |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <10mm> |
