Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-10
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil every 500km of cumulative travel.
For vertical mounting, install an air brake module (ACM-5 accessory recommended).
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-10 Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Compact Adjustable Series
- Full model: ACEJ50X100-10
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable with ±0.5mm precision)
- Operating pressure: 0.1~0.9 MPa
- Cushioning: Adjustable elastic buffer
- Piston speed: 50~800 mm/s
- Ambient temperature: -20℃ to +80℃
- Mounting type: Basic (axial mounting)
- Port size: 1/4" NPT (G1/8 optional)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR wear-resistant seals
- Weight: 1.8 kg (with standard accessories)
- Dimensions (L×W×H): 196mm × 63mm × 63mm
- ISO standard: 6432 (25mm~100mm stroke compliance)
High-precision compact cylinder featuring a dual-axis adjustable stroke mechanism with locknut fixation. The tapered cushion design reduces end-impact noise to ≤70dB. Includes built-in magnet for sensor mounting, compatible with all major brand proximity sensors. Anti-rotation guide structure ensures stable linear motion.
Industrial Applications:
- PCB handling robots in electronics assembly
- Precision clamping devices in CNC tool changers
- Carton folding mechanism in packaging lines
- Automated valve actuators in water treatment
- Material stop gates in conveyor systems
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil every 500km of cumulative travel.
For vertical mounting, install an air brake module (ACM-5 accessory recommended).
Stroke Adjustment:
- Loosen both end locknuts using 8mm wrench
- Rotate adjustment screws (M6×1.0 pitch) for micro-positioning
- Re-tighten locknuts to 2.5N·m torque
- Verify stroke with dial indicator
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-10 |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
