Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-100
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation tip:
Use locknuts on both sides of mounting brackets to prevent rotation during vibration.
For vertical mounting, install rod-end down to prevent condensate accumulation.
Lubricate every 3 months under normal operation (ISO VG32 equivalent oil).
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-100 Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 (50mm/63mm bore sizes)
- Full model: ACEJ50X100-100
- Bore size: 50mm
- Stroke: 100mm (adjustable through ±5mm stroke adjustment screw)
- Operating pressure: 0.1~0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion (dual-side)
- Port size: 1/4" NPT (G1/8 optional)
- Mounting types: Foot-mounted, front flange (FF), rear flange (MF)
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Seals: NBR standard (FKM available for high-temp versions)
- Weight: 1.25kg (with standard accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (at mid-stroke position)
- Protection class: IP40 (dust protected)
- Piston speed: 50~800 mm/s (lubricated condition)
Compact-profile cylinder (25% shorter than standard ISO cylinders) featuring dual-position adjustable stroke mechanism. The hexagonal body design allows wrench tightening during installation. Precision honed tube with integrated magnet slot for position sensing compatibility. Ideal for space-constrained automation requiring stroke flexibility.
Typical Applications:
- PCB handling robots requiring precise positioning
- Food packaging machines with frequent stroke adjustments
- Medical device assembly with limited cabinet space
- Automated conveyor diverters needing shock absorption
Installation tip:
Use locknuts on both sides of mounting brackets to prevent rotation during vibration.
For vertical mounting, install rod-end down to prevent condensate accumulation.
Lubricate every 3 months under normal operation (ISO VG32 equivalent oil).
Note:
Maximum side load capacity 15N·m. Avoid using in environments with
corrosive gases or abrasive particles exceeding 50μm.
Stroke adjustment must be performed with depressurized system.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-100 |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
