Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-100SB
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-100SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation notes:
1. Lubricate with ISO VG32 hydraulic oil before initial use
2. Max side load: ≤15% of theoretical thrust at 0.5MPa
3. For vertical mounting, use anti-drop mechanism (optional lock nut available)
4. Cushion adjustment: Turn clockwise to increase damping force (1 full rotation ≈ 30% damping change)
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-100SB Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Adjustable Compact Series
- Full model: ACEJ50X100-100SB
- Bore size: 50mm (ACEJ63 available for 63mm variant)
- Stroke: 100mm (adjustable cushion range: 5-20% of stroke)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -10℃ to 70℃
- Port size: G1/8 (NPT1/8 optional)
- Cushion type: External adjustable rubber + fixed air cushion
- Piston speed: 50–800 mm/s
- Mounting type: Basic (Standard) with front flange
- Rod end: Female thread M10×1.25
- Body material: Aluminum alloy (anodized surface)
- Seal material: NBR/PU (oil & heat resistant)
- Weight: 1.45 kg (with accessories)
- Dimensions:
- Length: 213mm (full extension)
- Width: 62mm (mounting flange span)
- Height: 62mm (square body profile)
- ISO certification: Complies with ISO 6432 standard
High-precision compact cylinder featuring dual-stage adjustable cushioning mechanism for smooth end-of-stroke deceleration. The T-slot design allows 360° adjustable mounting positions and tool-free cushion adjustment. Nickel-plated piston rod provides enhanced corrosion resistance for humid environments.
Typical Applications:
- Precision positioning in semiconductor handling robots
- Vertical actuation in packaging machine clamp systems
- Material transfer in CNC auto-loading mechanisms
- Press-fit operations in automotive assembly lines
- Medical device manufacturing automation
Installation notes:1. Lubricate with ISO VG32 hydraulic oil before initial use
2. Max side load: ≤15% of theoretical thrust at 0.5MPa
3. For vertical mounting, use anti-drop mechanism (optional lock nut available)
4. Cushion adjustment: Turn clockwise to increase damping force (1 full rotation ≈ 30% damping change)
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-100SB |
| Adjustable Stroke | 100mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
