Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-10B
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-10B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
For vertical mounting, install locking nut (accessory code LN-12)
to prevent piston rod rotation. Maintain 5mm minimum clearance
behind cylinder for full cushioning effectiveness.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-10B Adjustable Compact Cylinder Specifications
- Model Series: ACEJ50~63
- Specific Model: ACEJ50X100-10B
- Bore Size: 50mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating Pressure: 0.05~1.0 MPa
- Cushioning Type: Adjustable buffer (both ends)
- Mounting Style: Basic foot & front flange (ISO 15552 standard)
- Port Size: G1/8 (NPT1/8 optional)
- Piston Rod Thread: M12×1.25
- Ambient Temperature: -20℃ to 80℃
- Piston Speed: 50~800 mm/s
- Material: Aluminum alloy barrel, CR12MoV hardened piston rod
- Seal Material: NBR with wear-resistant ring
- Weight: 1.3kg (excluding accessories)
- Dimensions: 200mm(L) × 50mm(W) × 62mm(H)
- Repeat Positioning Accuracy: ±0.2mm
- Protection Class: IP54 (standard), IP67 optional
High-precision compact cylinder featuring dual adjustable pneumatic cushions for smooth stroke termination. The anodized aluminum construction provides corrosion resistance in humid environments. Integrated mounting grooves allow direct sensor installation for position feedback. Includes wear-resistant rod seals rated for 3,000km+ service life.
Typical Applications:
- Precision clamping in CNC tool changers
- Vertical lifting mechanisms in packaging lines
- Part positioning in semiconductor handling robots
- Actuation in cleanroom-compatible machinery
- Material gate control in automated sorting systems
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
For vertical mounting, install locking nut (accessory code LN-12)
to prevent piston rod rotation. Maintain 5mm minimum clearance
behind cylinder for full cushioning effectiveness.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-10B |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
