Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-10S
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Operation tip:
For optimal performance, maintain 0.3-1.0 MPa operating pressure and use 40μm filtered air.
Allow 3mm clearance around cylinder body for heat dissipation during continuous cycling.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-10S Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Compact Series
- Model: ACEJ50X100-10S
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.1~0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: 1/4" NPT (G1/8 optional)
- Mounting type: Basic type (MF1) with foot mounting option
- Piston material: Die-cast aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR + PU combination seals
- Weight: 1.25 kg (without accessories)
- Dimensions: 200mm(L) × 52mm(W) × 52mm(H) (retracted length)
- Stroke tolerance: ±1.5mm
- Max theoretical force: 176.7N @0.5MPa (extending)
- Speed range: 50~700 mm/s
- Lubrication: Pre-lubricated (non-relubrication design)
Ultra-slim profile cylinder with stroke adjustment mechanism (rotary lock nut system). Features integrated air cushion control with ±5° adjustable buffer needle. Dual-purpose front mounting slot accepts both metric and imperial fasteners. Built-in magnet for sensor mounting (compatible with CS1 series sensors).
Industrial Applications:
- Precision clamping in CNC tool changers
- Vertical lifting mechanisms in packaging lines
- Material positioning in semiconductor handling
- Gate control in food processing machinery
- Automated welding fixture actuation
Operation tip:
For optimal performance, maintain 0.3-1.0 MPa operating pressure and use 40μm filtered air.
Allow 3mm clearance around cylinder body for heat dissipation during continuous cycling.
Configuration options:
- Rod end types: Male/Female thread (M10×1.25 or 1/2"-20 UNF)
- Accessory kits: Includes cushion needle tool and mounting templates
- Custom stroke lengths available in 25mm increments (25-300mm)
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
