Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-10SB
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-10SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation note:
Maintain 0.05mm max lateral misalignment during mounting. For vertical installations exceeding 500mm/s speed,
use external stopper. Lubricate rod weekly in high-cycle applications (>500,000 cycles/month).
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-10SB Adjustable Compact Cylinder Specifications
- Model Series: ACEJ50~63 (50mm/63mm bore options)
- Full Model: ACEJ50X100-10SB
- Bore Size: 50mm (standard series)
- Stroke: 100mm (adjustable ±5% via cushion mechanism)
- Operation Type: Double-acting with auto-switch compatibility
- Working Pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Medium Temperature: -20℃ to 80℃ (dry air required below 0℃)
- Cushion Type: Adjustable rubber buffer (both ends)
- Mounting Style: Basic type (optional foot/rod flange: -11/-14 suffix)
- Port Size: M5×0.8 (standard), optional NPT1/8
- Piston Rod Thread: M10×1.25 (external)
- Material: Aluminum alloy barrel, hard-anodized piston rod
- Seal Material: NBR (standard), optional FKM for high temp
- Protection Class: IP65 (wipers included)
- Weight: 1.8kg ±5% (without accessories)
- Dimensions (L×W×H): 230×63×63mm (extended length)
- Stroke Tolerance: +2.0mm/-0mm
- Optional Features: Magnetic piston (-M suffix), auto switches (S-8/S-10)
High-precision compact cylinder featuring reduced "dead length" design (25% shorter than standard models) with progressive cushioning adjustment. The hexagonal barrel design enables tool-free rotation prevention. Corrosion-resistant construction with 5000km minimum service life under rated conditions. Requires 40μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
Typical Applications:
- High-speed pick-and-place systems in electronics assembly
- Precision clamping devices for CNC tooling
- Compact packaging machinery with space constraints
- Automated test equipment requiring position feedback
- Cleanroom-compatible material handling systems
Installation note:
Maintain 0.05mm max lateral misalignment during mounting. For vertical installations exceeding 500mm/s speed,
use external stopper. Lubricate rod weekly in high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
