Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-20B
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-20B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation note:
Maintain 0.5mm minimum clearance between stopper and cylinder during adjustment.
For vertical mounting, use model suffix "-20BV" with reinforced rod end bearing.
Lubricate guide rod monthly in dusty environments.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-20B Specifications
- Model: ACEJ50X100-20B
- Series: ACEJ50~63 (50mm/63mm bore sizes)
- Bore size: 50mm
- Stroke: 100mm (±1.5mm tolerance)
- Adjustable stroke: ±20mm via external stopper
- Mounting type: Basic foot mounting (ISO 15552 standard)
- Port size: M5×0.8 (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Air cushion adjustable with needle valve (both ends)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Piston speed: 50–800 mm/s (optimal range 100–500 mm/s)
- Weight: 1.85 kg (with standard accessories)
- Dimensions:
- Length: 205mm (minimum retracted length)
- Width: 72mm (mounting foot span)
- Height: 62mm (cylinder body diameter)
- Rod thread: M16×1.5 (external)
- Protection rating: IP54 (standard), IP67 available on request
Compact profile cylinder with unique stroke adjustment mechanism, featuring dual-side shock absorption and precision HNBR seals. The tapered piston design reduces air consumption by 15% compared to standard models. Includes magnetic piston for sensor compatibility and anti-rotation guide rod for precise linear motion. Requires ISO VG32 hydraulic oil lubrication if used in high-cycle applications (>500,000 cycles/year).
Typical Applications:
- Precision positioning in robotic welding arms
- Clamping fixtures for CNC machining centers
- Vertical lifting mechanisms in packaging lines
- Material handling in cleanroom environments
- Automated test equipment position adjustment
Installation note:
Maintain 0.5mm minimum clearance between stopper and cylinder during adjustment.
For vertical mounting, use model suffix "-20BV" with reinforced rod end bearing.
Lubricate guide rod monthly in dusty environments.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-20B |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
