Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-20S
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation Tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use locking collar (LC-50 accessory) to prevent
unintended stroke changes. Lubricate with ISO VG32 turbine oil if
operating below -10℃.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-20S Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Adjustable Compact Cylinder
- Model Code: ACEJ50X100-20S
- Bore Size: 50mm (Standard ACEJ Series)
- Stroke: 100mm (Adjustable with ±5mm fine-tuning capability)
- Operating Pressure: 0.05~0.9 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Dual adjustable rubber buffers (front/rear)
- Mounting Style: Basic foot mount (ISO 15552 standard accessory compatibility)
- Port Size: G1/8 (NPT1/8 optional)
- Piston Material: Anodized aluminum alloy with wear-resistant coating
- Rod Material: Hard chrome-plated steel (Cr-Mo steel core)
- Seal Type: NBR seals (FKM/Viton optional for high-temp)
- Weight: 1.65kg (including standard accessories)
- Dimensions:
- Length: 230mm (full extension)
- Body Width: 63mm (max cross-section)
- Height: 76mm (mounting base to rod center)
- Position Detection: Pre-drilled slots for magnetic sensors (SM/SMF series compatible)
- Cycle Life: 5,000km (under standard operating conditions)
High-precision compact cylinder featuring manual stroke adjustment mechanism with locking nut. The hexagonal piston rod prevents rotation during operation, while the dual cushioning system allows precise speed control. Anti-vibration design ensures stable performance in high-frequency applications (up to 5Hz). Includes corrosion-resistant treatment for humid environments.
Typical Applications:
- Precision positioning in semiconductor handling robots
- Clamping fixtures for CNC machine tooling
- Vertical lifting mechanisms in packaging lines
- Automated conveyor diverters in logistics systems
- Printing press paper feed adjustments
Installation Tip:
Maintain 0.5-1mm clearance between rod end and load during alignment.
For vertical mounting, use locking collar (LC-50 accessory) to prevent
unintended stroke changes. Lubricate with ISO VG32 turbine oil if
operating below -10℃.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
