Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-30
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-30
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation note:
Maintain 0.5mm alignment tolerance during mounting. For adjustable stroke operation,
lubricate stopper threads with ISO VG32 hydraulic oil monthly. Avoid lateral forces exceeding 30N.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-30 Specifications
- Model: ACEJ50X100-30
- Series: ACEJ50~63 (50mm/63mm bore sizes)
- Bore size: 50mm
- Stroke: 100mm (adjustable)
- Mounting type: Foot-mounted (ISO 15552 standard)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Air cushion with adjustable shock absorber
- Port size: G1/8 (NPT1/4 optional)
- Piston rod thread: M12×1.25
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Temperature range: -20℃ to 80℃
- Adjustable stroke mechanism: External mechanical stopper
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500mm/s
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: 1.65kg (without accessories)
- Dimensions:
- Length: 200mm (min extended) / 300mm (max extended)
- Width: 70mm (mounting foot span)
- Height: 50mm (barrel diameter)
- Certifications: ISO 6432, VDMA 24562
Space-optimized pneumatic cylinder featuring external stroke adjustment via rotary stoppers, enabling mid-stroke positioning without disassembly. The corrosion-resistant design incorporates dual scrapers for dust protection and silicone-free lubrication for cleanroom compatibility. Includes magnetic piston for position sensing (sensor not included).
Typical Applications:
- Precision clamping in CNC tool changers
- Vertical lifting mechanisms in packaging lines
- Part positioning in semiconductor handling robots
- Gate control in plastic injection molding
- Automated door actuators in clean environments
Installation note:
Maintain 0.5mm alignment tolerance during mounting. For adjustable stroke operation,
lubricate stopper threads with ISO VG32 hydraulic oil monthly. Avoid lateral forces exceeding 30N.
Environment Requirements:
- Use filtered air (5-40μm)
- Relative humidity <90% (non-condensing)
- Lubrication: ISO VG32 (recommended cycle: 3 million strokes)
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-30 |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
