Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-30SB
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-30SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation guidelines:
Use Loctite 243 on mounting screws. Lubricate with ISO VG32 turbine oil.
Maintain 0.3mm minimum clearance between rod end and load during alignment.
Cushion adjustment requires 1.5mm hex key (included).
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-30SB Specifications
- Model Series: ACEJ50~63 (50-63mm bore sizes)
- Specific Model: ACEJ50X100-30SB
- Bore Size: 50mm
- Stroke: 100mm (±0.5mm tolerance)
- Cushion Type: Adjustable pneumatic cushion (both ends)
- Mounting Style: Basic type (Standard) with optional foot mounting capability
- Operating Pressure: 0.15–0.8 MPa
- Temperature Range: -20℃ to 80℃
- Port Size: M5x0.8 (G1/8 adapter optional)
- Piston Speed: 50–800 mm/s
- Material: Aluminum alloy body, NBR seals
- Rod End: External thread M10x1.25
- Protection Rating: IP65 (standard wiper seal)
- Weight: 1.8kg (including all accessories)
- Dimensions:
- Total Length: 300mm (at full extension)
- Body Width: 53mm
- Height with Mounts: 62mm
- Centerline Height: 25mm
Precision-engineered compact cylinder featuring dual adjustable air cushions for controlled deceleration. The hexagonal body design allows wrench tightening and integrates mounting slots for flexible installation. Anti-rotation guide mechanism ensures stable linear motion. Includes built-in magnet for position sensing compatibility.
Industrial Applications:
- PCB handling robots in electronics manufacturing
- Clamping mechanisms in CNC fixture systems
- Carton flap adjustment in packaging lines
- Precision glass panel pressing equipment
- Automated test equipment positioning stages
Installation guidelines:
Use Loctite 243 on mounting screws. Lubricate with ISO VG32 turbine oil.
Maintain 0.3mm minimum clearance between rod end and load during alignment.
Cushion adjustment requires 1.5mm hex key (included).
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-30SB |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
