Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-40
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-40 Specifications
- Series: ACEJ50~63 (50mm/63mm bore sizes)
- Full model: ACEJ50X100-40
- Bore size: 50mm
- Stroke: 100mm (adjustable via external stop screws)
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Cushion type: Adjustable air cushion at both ends
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 1.45 kg (with standard accessories)
- Dimensions:
- Length (stroke extended): 200±2mm
- Body diameter: Φ50mm
- Mounting base: 63mm(W) × 40mm(H)
- ISO standard: 6432
- Protection rating: IP54 (standard wipers)
This space-saving cylinder features dual-position stroke adjustment (±5mm fine-tuning) through hexagonal locking screws, ideal for precision positioning tasks. The corrosion-resistant construction includes an anodized barrel and chrome-plated piston rod, supporting high-frequency operation up to 5 cycles/second. Requires 40μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Automated screw driving stations
- Semiconductor wafer handling robots
- Textile machinery thread guides
Installation note:
For vertical mounting, add a rod-end stabilizer (optional ASNU-50 accessory).
Maintain 0.3–0.5mm clearance between adjustable stoppers and cylinder body during calibration.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-40 |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
