Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-40B
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-40B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
Use locking nuts (M5x0.8) with 1.2-1.5N·m torque for sensor mounting.
Lubricate every 3 months under continuous operation.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-40B Specifications
- Series: ACEJ50~63 Compact Series
- Full model: ACEJ50X100-40B
- Bore size: 50mm (ACEJ63 indicates 63mm variant)
- Stroke: 100mm (adjustable ±5mm via cushion mechanism)
- Operating pressure: 0.1-0.9 MPa
- Piston speed: 50-750 mm/s
- Cushioning type: Adjustable rubber buffer (front/rear)
- Mounting type: 40B - Basic front flange with mounting holes
- Port size: M5x0.8 (Rc1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy body, CR/SUS piston rod
- Seal material: NBR (Nitrile) standard, optional FKM
- Weight: 1.25kg (without accessories)
- Dimensions:
- Length: 195mm (stroke 100mm + cylinder body)
- Width: 62mm (flange mounting base)
- Height: 62mm (square profile design)
- Protection class: IP40 (standard sealing)
- Lubrication: Pre-lubricated (DIN standard VG68 oil)
High-precision compact cylinder with space-saving design featuring 25% reduced length compared to standard cylinders. The double-acting design incorporates an auto-switch groove for sensor mounting and adjustable cushioning to prevent impact damage. The 40B mounting variant provides stable fixation for vertical/horizontal installations.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Carton box clamping mechanisms in packaging lines
- Precision positioning in semiconductor wafer stages
- Automated door locking systems in cleanrooms
- Medical device assembly actuators
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
Use locking nuts (M5x0.8) with 1.2-1.5N·m torque for sensor mounting.
Lubricate every 3 months under continuous operation.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-40B |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
