Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-40S
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Maintenance Tip:
Lubricate with ISO VG32 hydraulic oil mist lubrication. For vertical installations exceeding 45° angle,
use rod-end support brackets (sold separately) to prevent side load wear.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-40S Specifications
- Model Code Breakdown: ACEJ50X100-40S
- 50: Bore size (50mm)
- 100: Stroke length (100mm)
- 40: Cushion adjustment type
- S: Built-in magnetic sensor slot
- Bore Sizes Available: 50mm, 63mm (ACEJ series)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port Size: G3/8 (ISO standard)
- Piston Material: Aluminum alloy with hard anodizing
- Rod Material: Chrome-plated steel (Cr-Mo)
- Seal Material: NBR (Nitrile Rubber)
- Weight: 2.1 kg (excluding accessories)
- Dimensions:
- Total Length (Extended): 238mm
- Body Length: 138mm
- Width (Square Body): 76mm
- Height (Mounting Base): 50mm
- Rod End Thread: M10×1.25
- Max Theoretical Force:
- Thrust @0.63MPa: 1236N
- Retract @0.63MPa: 1065N
- Air Consumption: 1.96L/stroke @0.5MPa
- ISO Standard: 15552 (Compact cylinder variant)
This space-saving cylinder combines ISO 15552 performance in 20% smaller package, featuring dual adjustable cushions for precise end-position control. The square body design enables direct sensor mounting and multiple installation options via standardized mounting patterns. Special rod sealing structure reduces breakaway pressure to ≤0.08MPa.
Industrial Applications:
- Robotic material handling systems
- Pharmaceutical blister packaging machines
- Semiconductor wafer handling arms
- Automated test equipment positioning
- Food processing ejection mechanisms
Maintenance Tip:
Lubricate with ISO VG32 hydraulic oil mist lubrication. For vertical installations exceeding 45° angle,
use rod-end support brackets (sold separately) to prevent side load wear.
Configuration Options:
- Stroke adjustment: ±2mm via cushion screws
- Mounting variants: Fixed (MF1), front flange (MF2), rear flange (MF3)
- Sensor compatibility: D-A93 series magnetic switches
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-40S |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
