Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-50
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation tip:
Use M5 mounting screws with 14mm engagement depth (torque ≤ 7.8N·m).
Lubricate with ISO VG32 hydraulic oil before initial operation.
Allow 0.5mm clearance around piston rod for thermal expansion.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-50 Specifications
- Model Series: ACEJ50~63 (50mm/63mm bore sizes)
- Specific Model: ACEJ50X100-50
- Bore Size: 50mm
- Stroke: 100mm
- Adjustable Stroke Range: ±5mm (via external stopper)
- Operating Pressure: 0.05~0.9 MPa
- Operating Temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (front/rear)
- Mounting Style: Basic type (axial foot/rod flange optional)
- Port Size: Rc1/4 (G1/4 optional)
- Piston Speed: 50~750 mm/s
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal Material: NBR (nitrile rubber)
- Weight: 1.85 kg (without accessories)
- Dimensions (L×W×H):
- Extended Length: 220mm
- Retracted Length: 140mm
- Body Width: 63mm
- Mounting Height: 50mm
Space-saving cylinder with micro-adjustment capability through external stroke limiter. Features dual-side adjustable cushioning for precise end-position control and reduced impact noise. The anodized body provides corrosion resistance for humid environments. Includes built-in magnet for sensor compatibility.
Typical Applications:
- Precision positioning in robotic pick-and-place systems
- Clamping mechanisms in CNC machine tool changers
- Material handling in semiconductor manufacturing
- Automated packaging line actuators
- Textile machinery thread control systems
Installation tip:
Use M5 mounting screws with 14mm engagement depth (torque ≤ 7.8N·m).
Lubricate with ISO VG32 hydraulic oil before initial operation.
Allow 0.5mm clearance around piston rod for thermal expansion.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-50 |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
