Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-50B
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-50B Specifications
- Series: ACEJ50~63 Compact Series
- Full model: ACEJ50X100-50B
- Bore size: 50mm (63mm max in series)
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable elastic buffer (50B code)
- Mounting style: Basic foot/Flange mount
- Port size: M5x0.8 (standard), G1/8 optional
- Piston speed: 50-1000mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + PU combination
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 2.1kg (without accessories)
- Dimensions: 214mm(L) × 63mm(W) × 63mm(H)
- Repeat accuracy: ±0.5mm
- Protection class: IP40 (standard), IP67 optional
Space-optimized cylinder featuring dual-axis adjustable stroke mechanism with visible scale markings. The 50B variant incorporates a progressive buffer system with 10° rotation adjustment dial for precise end-position damping control. Integrated magnet slots enable sensor mounting without external brackets. Optimized air passage design reduces flow resistance by 18% compared to previous generations.
- High-density automation cells with limited space
- Precision part insertion in PCB assembly lines
- Variable stroke clamping devices
- Food packaging machines requiring frequent stroke adjustments
- Medical device actuation systems
Installation note:
For optimal performance, maintain 0.5-1mm clearance between cylinder body and machine frame.
Use anti-vibration washers when mounting on moving platforms. Lubricate through port #3 every
500km of cumulative stroke movement.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-50B |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
