Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-50SB
$76.27
Regular price
$83.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-50SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation guidelines:
Use locknuts (M10) for axial load support. Lubricate with ISO VG32 hydraulic oil.
For vertical mounting, install speed controller on cap side. Allow 15mm clearance
for stroke adjustment operation. Avoid side load exceeding 30N.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-50SB Adjustable Compact Cylinder Specifications
- Series: ACEJ50~63 Adjustable Compact Series
- Bore size: 50mm
- Stroke: 100mm (±0.5mm tolerance)
- Adjustment range: 50mm (manual stroke adjustment)
- Operating pressure: 0.1–0.9 MPa
- Port size: 1/4" NPT (G1/4 optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front/rear flange (NF series compatible)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Protection rating: IP40 (standard wiper design)
- Weight: 2.3kg (excluding accessories)
- Dimensions: 250mm(L) × 63mm(W) × 63mm(H) (max extended length)
- Rod thread: M10×1.25 (external)
- Piston speed: 50–700mm/s (lubricated condition)
Compact cylinder with integrated stroke adjustment mechanism, featuring space-saving design (30% shorter than standard cylinders). Precision ground rod and double-sealing structure ensure leak-proof operation. Includes magnetic piston for position sensing compatibility. Manual locking screw allows ±25% stroke modification during operation.
Typical Applications:
- Precision clamping in CNC tool changers
- Variable stroke applications in packaging sealing machines
- Position adjustment in semiconductor handling equipment
- Space-constrained automation cells
- Pick-and-place systems requiring stroke flexibility
Installation guidelines:
Use locknuts (M10) for axial load support. Lubricate with ISO VG32 hydraulic oil.
For vertical mounting, install speed controller on cap side. Allow 15mm clearance
for stroke adjustment operation. Avoid side load exceeding 30N.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-50SB |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
