Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-75
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 30N.
For vertical mounting, use locking nut (ASNU5) to prevent stroke drift. Allow 5mm clearance
behind adjustment screw for maintenance access.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50X100-75 Adjustable Compact Cylinder Specifications
- Model Series: ACEJ50~63 (50mm/63mm bore sizes)
- Specific Model: ACEJ50X100-75
- Bore Size: 50mm
- Stroke: 100mm (with ±75° adjustable stroke via external screw)
- Adjustment Range: 25-100mm (mechanical stroke limitation)
- Operating Pressure: 0.05~0.9 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable air cushion
- Port Size: G1/8 (M5 optional)
- Mounting: Standard foot mounting (MF1) with optional front flange
- Rod Material: Hard chrome-plated steel
- Tube Material: Anodized aluminum alloy
- Seal Material: NBR (Nitrile rubber)
- Weight: 1.35kg (without accessories)
- Dimensions: 180mm(L) × 60mm(W) × 60mm(H) (retracted length)
A space-saving linear actuator featuring patented stroke adjustment mechanism with visual position indicators. The dual-cushion design minimizes end-impact noise while maintaining positioning accuracy (±0.5mm repeatability). Integrated mounting grooves allow direct sensor installation for position feedback. Compatible with ISO 6432 mounting accessories.
Typical Applications:
- Precision clamping in CNC tool changers
- Variable stroke applications in packaging machinery
- Position-adjustable stops in conveyor systems
- Laboratory equipment requiring cleanroom compatibility
- Automated door mechanisms with space constraints
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 30N.
For vertical mounting, use locking nut (ASNU5) to prevent stroke drift. Allow 5mm clearance
behind adjustment screw for maintenance access.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-75 |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
