Airtac ACEJ50~63 Adjustable Compact Air Cylinder ACEJ50X100-75B
$73.94
Regular price
$81.44
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACEJ50X100-75B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The AIRTAC ACEJ50~63 Compact Adjustable Cylinder series delivers optimized performance through advanced engineering:
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
Installation Tip:
When using full stroke adjustment range, reduce operating pressure by 20% to compensate for increased moment load. Locking nuts require 2.5-3.5 N·m torque using the included hex key. Regular cleaning of position scale grooves prevents debris accumulation.
1. Compliant with ISO 21287 standards, featuring high interchangeability of mounting dimensions;
2. Threaded connection between cylinder body and end caps ensures enhanced structural integrity and maintenance-friendly design;
3. Precision-honed bore surface with hard anodized coating for superior wear resistance and extended service life;
4. Patented asymmetrical bidirectional piston sealing configuration combines compact dimensions with integrated oil reservoir functionality;
5. Space-efficient profile reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided T-slot configuration enables tool-less sensor mounting and positional feedback integration;
7. Integrated cushioning system effectively absorbs residual kinetic energy from high-speed operation and mechanical inertia;
8. Comprehensive selection of standardized mounting accessories available for flexible system integration.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: ACEJ50~63
AirTAC ACEJ50~63 Adjustable Compact Cylinder ACEJ50X100-75B Specifications
- Model Series: ACEJ50~63 (Adjustable Stroke Compact Cylinder)
- Specific Model: ACEJ50X100-75B
- Bore Size: 50mm
- Standard Stroke: 100mm
- Adjustment Range: ±75mm (Total stroke variation 150mm)
- Operating Pressure: 0.05–1.0 MPa
- Cushioning Type: Rubber bumper + adjustable external stopper
- Port Size: M5x0.8 (G1/8 optional)
- Mounting Style: Basic type (B code) with through-hole mounting
- Rod Thread: M10x1.25 (ISO standard)
- Piston Material: Aluminum alloy with hard anodizing
- Rod Material: Chrome-plated carbon steel
- Seal Type: NBR seals (Fluorine rubber available for high-temp versions)
- Ambient Temperature: -20℃ to 80℃ (standard seals)
- Weight: 1.25kg (excluding accessories)
- Dimensions:
- Extended Length: 285mm (max stroke position)
- Retracted Length: 185mm (min stroke position)
- Body Width: 63mm
- Height with Mounts: 82mm
- Protection Class: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (Oil-free operation possible)
The ACEJ50X100-75B features a unique dual-position locking mechanism with visual stroke indicators, allowing millimeter-level precision adjustments without disassembly. Its space-saving design integrates a built-in flow control valve for speed regulation. The hardened piston rod and anti-rotation guide slots ensure stable operation in high side-load applications.
Typical Applications:
- Variable height work platforms in assembly lines
- Precision clamping fixtures for CNC machining centers
- Adjustable stoppers in automotive welding jigs
- Packaging machine product height compensators
- Semiconductor handling equipment positioners
Installation Tip:
When using full stroke adjustment range, reduce operating pressure by 20% to compensate for increased moment load. Locking nuts require 2.5-3.5 N·m torque using the included hex key. Regular cleaning of position scale grooves prevents debris accumulation.
| Property | Property Value |
|---|---|
| sku | ACEJ50X100-75B |
| Adjustable Stroke | 75mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
